North Atlantic Aerosols and Marine Ecosystems Study

Chilled Mirror Hygrometers (CMHs) are in situ sensors that directly measure dew point temperature by collecting water vapor on a chilled mirror surface. The mirror's temperature is lowered with thermoelectric coolers until water vapor from the sample gas condenses as dew or frost. The mirror's temperature is then measured using a platinum resistance thermometer (PRT) to determine the dew point and humidity. CMHs have been utilized on both airborne and ground-based platforms and serve as the NIST traceable reference standard for calibrating other sensors.

The Cloud Droplet Probe (CDP) is an in situ cloud probe manufactured by Droplet Measurement Technologies. It measures the particle size distribution and concentration for cloud particles in the 2-50 μm size range. CDP detects pulses of light scattered from a laser (658 nm) to count and size individual cloud droplets. CDP has a typical measurement rate of 1 Hz and can detect concentrations of up to 2000 particles per cubic centimeter.

The Aerosol Mass Spectrometer (AMS) is an in situ spectrometer developed by Aerodyne Research. It employs quadrupole mass spectrometry to measure aerosol chemical composition and properties. It can detect particles ranging from 40 nm to 1 micron in size and has a time resolution of up to 10 Hz. It can be installed on aircraft, research vessels, mobile laboratories, or other ground-based platforms.

Condensation Particle Counters (CPCs) are in situ sensors that measure aerosol particle concentrations. CPCs determine aerosol levels by condensing fluid onto particles, causing them to grow to sizes detectable by optical scattering. Typically, CPCs can detect particles ranging from 7 nm to 3 μm, measure concentrations up to 100,000 particles per cubic centimeter, and provide readings every second. CPCs are manufactured by TSI Incorporated and can be used on airborne, shipborne, and ground-based platforms.

The Laser Aerosol Spectrometer (LAS) is an in situ airborne spectrometer manufactured by TSI, Inc. LAS measures particle size by analyzing how particles scatter light. It operates at a 633 nm wavelength and detects particles ranging from 0.09 to 7.5 μm. LAS can deliver complete particle size distributions at a rate of 10 Hz. It is commonly used as part of aerosol instrument suites, such as NASA’s Langley Aerosol Research Group Experiment (LARGE) and NOAA’s Aerosol Microphysical Properties (AMP).

The Particle Soot Absorption Photometer (PSAP) is an in situ airborne photometer manufactured by Radiance Research. It applies Beer's Law to measure the change in light transmission of aerosol particles. These measurements help determine aerosol absorption and extinction. PSAP operates across three wavelengths (467, 530, and 660 nm) and has a 1-second time resolution. It is usually deployed on aircraft, but it can also be used on ships and vehicles.

Generic-Atmospheric State (Gen-AtmsState) refers to non-specific instruments on a platform used for measurements of atmospheric state parameters. These are typically in situ sensors that measure temperature, pressure, humidity, and wind speed/direction. Types of atmospheric state instruments include thermometers, hygrometers, barometers, and anemometers.

The Proton Transfer Mass Spectrometer (PTR-MS) is an in situ spectrometer used both on aircraft and ground, developed by the University of Innsbruck in Austria. It detects volatile organic compounds (VOCs) without the need for sample preparation at very low concentrations. PTR-MS employs chemical ionization mass spectrometry, enabling quick and highly sensitive VOC detection. It has a signal integration time ranging from 0.5 to 1 second.

The Research Scanning Polarimeter (RSP) is an airborne, passive polarimeter developed by SpecTIR Corporation. It measures total radiance and linear polarization across nine spectral bands in the visible and infrared wavelengths (410-2250 nm). These measurements can be used to determine aerosol and cloud properties. RSP has a time resolution of 0.8 seconds, a field of view of 14 mrad, and a horizontal resolution of approximately 100 meters at an altitude of 5 km.

The Scanning Mobility Particle Sizer (SMPS) is an in situ aerosol sensor that can be operated on airborne or ground-based platforms, manufactured by TSI Incorporated. SMPS uses a differential mobility analyzer (DMA) to measure the electrical mobility diameter of aerosol particles, which helps determine the size distribution. It also counts the number of aerosol particles using a condensation particle counter (CPC). It detects particles in the size range of 10-1000 nm and typically takes about 10 seconds to complete each scan.

The Ultra-High Sensitivity Aerosol Spectrometer (UHSAS) is an in situ spectrometer developed by Droplet Measurement Technologies. It can be used on both airborne and ground-based platforms to measure aerosol size distribution and concentration. UHSAS determines particle size by detecting the peak light signals from aerosol particles illuminated by a 1054 nm laser. It can sample particles in the 60–1000 nm size range and operates at a sampling frequency of 10 Hz.

The Spectrometers for Sky-Scanning, Sun-Tracking Atmospheric Research (4-STAR) is an airborne sun-sky spectrometer that measures direct solar irradiance and sky radiance. These measurements can be used to retrieve column-integrated information on aerosols, clouds, and trace gases such as aerosol optical depth, extinction, and single scattering albedo. 4-STAR operates in the 350-1650 nm wavelength range and has a typical horizontal resolution of about 100 m.

The Single Particle Soot Photometer (SP2) is an in situ laser-induced photometer developed by Droplet Measurement Technologies. SP2 measures the black carbon (BC) mass in individual aerosol particles, along with their optical and physical properties that contain BC. The device detects aerosol particles with diameters of 200-400 nm and can analyze up to 25,000 particles per second. It operates at a sampling rate of 1 Hz and uses a wavelength of 1.06 μm. It can be used on airborne or ground-based platforms and paired with a Humidified-Dual SP2 (HD-SP2).

The Aerodynamic Particle Sizer (APS) is an in situ spectrometer manufactured by TSI Instruments. APS measures aerodynamic particles in the 0.5-20 μm size range. It also measures the light-scattering intensity of the particles in the 0.37-20 μm optical size range. APS provides particle size distributions for 52 channels at a typical sampling time of 1 second. It uses a laser diode operating at 655 nm and has a size resolution of 0.02 μm at 1 μm. APS can be deployed on aircraft, ships, or ground-based platforms.

The Condensation Nuclei Counter (CNC) is an in situ optical sensor produced by Droplet Measurement Technologies. It detects cloud condensation nuclei (CCN) by supersaturating the sampled air, allowing CCN particles to become detectable. The particles are then measured with an optical particle counter (OPC). CNC can detect particles from 0.75 to 10 μm in diameter and operates at a sampling rate of 1 Hz. It is suitable for both airborne and ground-based operations.

The Cloud Imaging Probe (CIP) is an in situ airborne optical array probe manufactured by Droplet Measurement Technologies. It captures cloud particle images by recording shadows as particles pass through a laser. Additionally, it provides data on particle size distribution and cloud liquid water content. CIP typically has a resolution of 25 μm and can measure particles ranging from 12.5 μm to 1.55 mm.

The High Spectral Resolution Lidar (HSRL) is an airborne lidar system developed at NASA Langley Research Center (LaRC). It uses the HSRL technique at 532 nm and the standard backscatter technique at 1064 nm to provide profile measurements of aerosol backscatter, extinction, and depolarization. The profiles of aerosol backscatter and depolarization typically have a vertical resolution of 30 m and a horizontal resolution of about 1 km. For the extinction profiles, the vertical resolution is 300 m with a horizontal resolution of approximately 6 km. HSRL is usually flown during investigations to validate observations from the CALIPSO spaceborne lidar.

Nephelometers are in situ optical sensors that can be airborne or ground-based. They measure the total scattering and backscattering of aerosol particles in the atmosphere. Nephelometers operate at three wavelengths: 450 nm, 550 nm, and 700 nm, with a typical time resolution of 1 Hz.

The Cloud and Aerosol Spectrometer (CAS) is an in situ airborne spectrometer manufactured by Droplet Measurement Technologies. It measures light scattering at 658 nm to determine aerosol and cloud particle size distributions from 0.51 to 50 μm. It also provides measurements of the refractive index and particle shape. CAS has a typical time resolution of 1 Hz and can measure concentrations greater than 1,000 particles per cubic meter.

The Los Gatos Research (LGR) Greenhouse Gas Analyzer (GGA) is a portable analyzer suitable for in situ measurements, either airborne or ground-based. It utilizes off-axis integrated cavity output spectroscopy (OA-ICOS) technology to simultaneously measure methane (CH4), carbon dioxide (CO2), and water vapor (H2O). It can detect CH4 levels up to 100 ppm, CO2 up to 20,000 ppm, and H2O up to 30,000 ppm. The device offers a selectable measurement rate ranging from 0.01 to 1 Hz, with some models featuring a fast flow option capable of rates up to 10 Hz.

GEOstationary Coastal and Air Pollution Events (GEO-CAPE) Airborne Simulator (GCAS) is an airborne push-broom instrument with two spectrometers. It was developed by the Radiometric Calibration and Flight Development Laboratory at Goddard Space Flight Center (GSFC) as a simulator for the GEO-CAPE mission. The first spectrometer in GCAS operates in the ultraviolet to visible (300-490 nm) range for air quality observations of nitrogen dioxide (NO2), ozone (O3), formaldehyde (HCHO), and other trace gases. The second spectrometer operates in the visible to near-infrared (480-900 nm) range to provide measurements of ocean color. GCAS has a typical spatial resolution of 250m across track and 500m along track at an altitude of 9 km, with a frame rate of 12 Hz.

The Langley Aerosol Research Group Experiment (LARGE) is an in situ airborne instrument suite that measures aerosol and cloud microphysical and optical properties, such as size distribution, number concentration, and scattering and absorption coefficients. LARGE includes several instruments, such as the Ultra-High Sensitivity Aerosol Spectrometer (UHSAS), Particle-Into-Liquid Sampler (PILS), Particle Soot Absorption Photometer (PSAP), Cloud and Aerosol Spectrometer (CAS), Cloud Imaging Probe (CIP), and additional cloud and aerosol sensors. The LARGE instruments operate over the 450-700 nm wavelength range, detect particles ranging from 0.003 to 20 μm, and measure at a frequency of 1 Hz. It is primarily used for airborne measurements but can also be deployed on ground-based platforms like vehicles.

Condensation Particle Counters (CPCs) are in situ sensors that measure aerosol particle concentrations. CPCs determine aerosol levels by condensing fluid onto particles, causing them to grow to sizes detectable by optical scattering. Typically, CPCs can detect particles ranging from 7 nm to 3 μm, measure concentrations up to 100,000 particles per cubic centimeter, and provide readings every second. CPCs are manufactured by TSI Incorporated and can be used on airborne, shipborne, and ground-based platforms.

The Aerosol Mass Spectrometer (AMS) is an in situ spectrometer developed by Aerodyne Research. It employs quadrupole mass spectrometry to measure aerosol chemical composition and properties. It can detect particles ranging from 40 nm to 1 micron in size and has a time resolution of up to 10 Hz. It can be installed on aircraft, research vessels, mobile laboratories, or other ground-based platforms.

The Single Particle Soot Photometer (SP2) is an in situ laser-induced photometer developed by Droplet Measurement Technologies. SP2 measures the black carbon (BC) mass in individual aerosol particles, along with their optical and physical properties that contain BC. The device detects aerosol particles with diameters of 200-400 nm and can analyze up to 25,000 particles per second. It operates at a sampling rate of 1 Hz and uses a wavelength of 1.06 μm. It can be used on airborne or ground-based platforms and paired with a Humidified-Dual SP2 (HD-SP2).

The Fourier Transformation Spectrometer (FTS) is a high-resolution spectrometer used both in airborne and ground-based applications. FTS measures the solar radiance reflected from the surface, which can be used to estimate levels of carbon monoxide (CO), carbon dioxide (CO2), and methane (CH4) in the atmosphere. It offers a spatial resolution of approximately 100m by 1000m and operates at a measurement frequency of 1 Hz during typical research flights.

Generic-Atmospheric State (Gen-AtmsState) refers to non-specific instruments on a platform used for measurements of atmospheric state parameters. These are typically in situ sensors that measure temperature, pressure, humidity, and wind speed/direction. Types of atmospheric state instruments include thermometers, hygrometers, barometers, and anemometers.

The Two Stage Viable Andersen Cascade Impactor (ACI) is an in situ impactor for aerosol sampling. It is used when the size distribution is not required and only the total particle counts are needed for analysis. The sampled air flows through the instrument, and the aerosol particles are collected on the corresponding plates within the two sampling stages. Larger particles (> 8 μm) are collected in the first stage, while smaller particles (0.8-8 μm) are collected in the second stage. It has an exact flow rate of 28.3 liters per minute.

Nephelometers are in situ optical sensors that can be airborne or ground-based. They measure the total scattering and backscattering of aerosol particles in the atmosphere. Nephelometers operate at three wavelengths: 450 nm, 550 nm, and 700 nm, with a typical time resolution of 1 Hz.

The Thermal Dissociation-Chemical Ionization Mass Spectrometer (TD-CIMS) is an in situ spectrometer operated by the Ultrafine Aerosol Research Group at UC Irvine. It analyzes the chemical composition of aerosol particles as small as 4 nm by combining nanoparticle separation and collection methods with selected ion chemical ionization mass spectrometry. TD-CIMS has a time resolution of 3 minutes and has been employed in field and laboratory aerosol research.

The Aerodynamic Particle Sizer (APS) is an in situ spectrometer manufactured by TSI Instruments. APS measures aerodynamic particles in the 0.5-20 μm size range. It also measures the light-scattering intensity of the particles in the 0.37-20 μm optical size range. APS provides particle size distributions for 52 channels at a typical sampling time of 1 second. It uses a laser diode operating at 655 nm and has a size resolution of 0.02 μm at 1 μm. APS can be deployed on aircraft, ships, or ground-based platforms.

The Particle Soot Absorption Photometer (PSAP) is an in situ airborne photometer manufactured by Radiance Research. It applies Beer's Law to measure the change in light transmission of aerosol particles. These measurements help determine aerosol absorption and extinction. PSAP operates across three wavelengths (467, 530, and 660 nm) and has a 1-second time resolution. It is usually deployed on aircraft, but it can also be used on ships and vehicles.

Thermo Scientific Gas Analyzers are in situ gas analyzers manufactured by ThermoFisher Scientific. They provide precise measurements of various trace gases such as ozone, carbon dioxide, carbon monoxide, and sulfur dioxide. Thermo Scientific Gas Analyzers can be deployed on aircraft, research vessels, and ground-based platforms.

The Condensation Nuclei Counter (CNC) is an in situ optical sensor produced by Droplet Measurement Technologies. It detects cloud condensation nuclei (CCN) by supersaturating the sampled air, allowing CCN particles to become detectable. The particles are then measured with an optical particle counter (OPC). CNC can detect particles from 0.75 to 10 μm in diameter and operates at a sampling rate of 1 Hz. It is suitable for both airborne and ground-based operations.

A thermosalinograph (TSG) is an in situ shipborne instrument used to measure sea surface temperature and conductivity. TSGs are typically mounted near the ship’s seawater intake where they collect continuous measurements. A TSG uses a conductivity cell and a thermistor cell to measure conductivity and temperature from underway vessels. These measurements can be used to derive salinity and other ocean parameters.

The Differential Mobility Analyzer (DMA) is an in situ device that measures particle electrical mobility to determine their size distribution. It mainly measures aerosols between 10 and 1,000 nm in diameter. DMA can be used for airborne, ground-based, and laboratory measurements.

Chilled Mirror Hygrometers (CMHs) are in situ sensors that directly measure dew point temperature by collecting water vapor on a chilled mirror surface. The mirror's temperature is lowered with thermoelectric coolers until water vapor from the sample gas condenses as dew or frost. The mirror's temperature is then measured using a platinum resistance thermometer (PRT) to determine the dew point and humidity. CMHs have been utilized on both airborne and ground-based platforms and serve as the NIST traceable reference standard for calibrating other sensors.

The Cloud Droplet Probe (CDP) is an in situ cloud probe manufactured by Droplet Measurement Technologies. It measures the particle size distribution and concentration for cloud particles in the 2-50 μm size range. CDP detects pulses of light scattered from a laser (658 nm) to count and size individual cloud droplets. CDP has a typical measurement rate of 1 Hz and can detect concentrations of up to 2000 particles per cubic centimeter.

The Aerosol Mass Spectrometer (AMS) is an in situ spectrometer developed by Aerodyne Research. It employs quadrupole mass spectrometry to measure aerosol chemical composition and properties. It can detect particles ranging from 40 nm to 1 micron in size and has a time resolution of up to 10 Hz. It can be installed on aircraft, research vessels, mobile laboratories, or other ground-based platforms.

Condensation Particle Counters (CPCs) are in situ sensors that measure aerosol particle concentrations. CPCs determine aerosol levels by condensing fluid onto particles, causing them to grow to sizes detectable by optical scattering. Typically, CPCs can detect particles ranging from 7 nm to 3 μm, measure concentrations up to 100,000 particles per cubic centimeter, and provide readings every second. CPCs are manufactured by TSI Incorporated and can be used on airborne, shipborne, and ground-based platforms.

The Laser Aerosol Spectrometer (LAS) is an in situ airborne spectrometer manufactured by TSI, Inc. LAS measures particle size by analyzing how particles scatter light. It operates at a 633 nm wavelength and detects particles ranging from 0.09 to 7.5 μm. LAS can deliver complete particle size distributions at a rate of 10 Hz. It is commonly used as part of aerosol instrument suites, such as NASA’s Langley Aerosol Research Group Experiment (LARGE) and NOAA’s Aerosol Microphysical Properties (AMP).

The Particle Soot Absorption Photometer (PSAP) is an in situ airborne photometer manufactured by Radiance Research. It applies Beer's Law to measure the change in light transmission of aerosol particles. These measurements help determine aerosol absorption and extinction. PSAP operates across three wavelengths (467, 530, and 660 nm) and has a 1-second time resolution. It is usually deployed on aircraft, but it can also be used on ships and vehicles.

Generic-Atmospheric State (Gen-AtmsState) refers to non-specific instruments on a platform used for measurements of atmospheric state parameters. These are typically in situ sensors that measure temperature, pressure, humidity, and wind speed/direction. Types of atmospheric state instruments include thermometers, hygrometers, barometers, and anemometers.

The Proton Transfer Mass Spectrometer (PTR-MS) is an in situ spectrometer used both on aircraft and ground, developed by the University of Innsbruck in Austria. It detects volatile organic compounds (VOCs) without the need for sample preparation at very low concentrations. PTR-MS employs chemical ionization mass spectrometry, enabling quick and highly sensitive VOC detection. It has a signal integration time ranging from 0.5 to 1 second.

The Research Scanning Polarimeter (RSP) is an airborne, passive polarimeter developed by SpecTIR Corporation. It measures total radiance and linear polarization across nine spectral bands in the visible and infrared wavelengths (410-2250 nm). These measurements can be used to determine aerosol and cloud properties. RSP has a time resolution of 0.8 seconds, a field of view of 14 mrad, and a horizontal resolution of approximately 100 meters at an altitude of 5 km.

The Scanning Mobility Particle Sizer (SMPS) is an in situ aerosol sensor that can be operated on airborne or ground-based platforms, manufactured by TSI Incorporated. SMPS uses a differential mobility analyzer (DMA) to measure the electrical mobility diameter of aerosol particles, which helps determine the size distribution. It also counts the number of aerosol particles using a condensation particle counter (CPC). It detects particles in the size range of 10-1000 nm and typically takes about 10 seconds to complete each scan.

The Ultra-High Sensitivity Aerosol Spectrometer (UHSAS) is an in situ spectrometer developed by Droplet Measurement Technologies. It can be used on both airborne and ground-based platforms to measure aerosol size distribution and concentration. UHSAS determines particle size by detecting the peak light signals from aerosol particles illuminated by a 1054 nm laser. It can sample particles in the 60–1000 nm size range and operates at a sampling frequency of 10 Hz.

The Spectrometers for Sky-Scanning, Sun-Tracking Atmospheric Research (4-STAR) is an airborne sun-sky spectrometer that measures direct solar irradiance and sky radiance. These measurements can be used to retrieve column-integrated information on aerosols, clouds, and trace gases such as aerosol optical depth, extinction, and single scattering albedo. 4-STAR operates in the 350-1650 nm wavelength range and has a typical horizontal resolution of about 100 m.

The Single Particle Soot Photometer (SP2) is an in situ laser-induced photometer developed by Droplet Measurement Technologies. SP2 measures the black carbon (BC) mass in individual aerosol particles, along with their optical and physical properties that contain BC. The device detects aerosol particles with diameters of 200-400 nm and can analyze up to 25,000 particles per second. It operates at a sampling rate of 1 Hz and uses a wavelength of 1.06 μm. It can be used on airborne or ground-based platforms and paired with a Humidified-Dual SP2 (HD-SP2).

The Aerodynamic Particle Sizer (APS) is an in situ spectrometer manufactured by TSI Instruments. APS measures aerodynamic particles in the 0.5-20 μm size range. It also measures the light-scattering intensity of the particles in the 0.37-20 μm optical size range. APS provides particle size distributions for 52 channels at a typical sampling time of 1 second. It uses a laser diode operating at 655 nm and has a size resolution of 0.02 μm at 1 μm. APS can be deployed on aircraft, ships, or ground-based platforms.

The Condensation Nuclei Counter (CNC) is an in situ optical sensor produced by Droplet Measurement Technologies. It detects cloud condensation nuclei (CCN) by supersaturating the sampled air, allowing CCN particles to become detectable. The particles are then measured with an optical particle counter (OPC). CNC can detect particles from 0.75 to 10 μm in diameter and operates at a sampling rate of 1 Hz. It is suitable for both airborne and ground-based operations.

The Airborne Tracking Sun Photometer (ATSP) is an airborne device that measures direct solar beam transmission. The ATSP captures solar beam transmission through multiple channels with wavelengths spanning from 354 to 2139 nm. These measurements can be used to determine aerosol optical depth and other aerosol characteristics. Several versions of this instrument exist, including one developed by the NASA Ames Research Center.

The Cloud Imaging Probe (CIP) is an in situ airborne optical array probe manufactured by Droplet Measurement Technologies. It captures cloud particle images by recording shadows as particles pass through a laser. Additionally, it provides data on particle size distribution and cloud liquid water content. CIP typically has a resolution of 25 μm and can measure particles ranging from 12.5 μm to 1.55 mm.

The High Spectral Resolution Lidar (HSRL) is an airborne lidar system developed at NASA Langley Research Center (LaRC). It uses the HSRL technique at 532 nm and the standard backscatter technique at 1064 nm to provide profile measurements of aerosol backscatter, extinction, and depolarization. The profiles of aerosol backscatter and depolarization typically have a vertical resolution of 30 m and a horizontal resolution of about 1 km. For the extinction profiles, the vertical resolution is 300 m with a horizontal resolution of approximately 6 km. HSRL is usually flown during investigations to validate observations from the CALIPSO spaceborne lidar.

Nephelometers are in situ optical sensors that can be airborne or ground-based. They measure the total scattering and backscattering of aerosol particles in the atmosphere. Nephelometers operate at three wavelengths: 450 nm, 550 nm, and 700 nm, with a typical time resolution of 1 Hz.

The Cloud and Aerosol Spectrometer (CAS) is an in situ airborne spectrometer manufactured by Droplet Measurement Technologies. It measures light scattering at 658 nm to determine aerosol and cloud particle size distributions from 0.51 to 50 μm. It also provides measurements of the refractive index and particle shape. CAS has a typical time resolution of 1 Hz and can measure concentrations greater than 1,000 particles per cubic meter.

The Los Gatos Research (LGR) Greenhouse Gas Analyzer (GGA) is a portable analyzer suitable for in situ measurements, either airborne or ground-based. It utilizes off-axis integrated cavity output spectroscopy (OA-ICOS) technology to simultaneously measure methane (CH4), carbon dioxide (CO2), and water vapor (H2O). It can detect CH4 levels up to 100 ppm, CO2 up to 20,000 ppm, and H2O up to 30,000 ppm. The device offers a selectable measurement rate ranging from 0.01 to 1 Hz, with some models featuring a fast flow option capable of rates up to 10 Hz.

GEOstationary Coastal and Air Pollution Events (GEO-CAPE) Airborne Simulator (GCAS) is an airborne push-broom instrument with two spectrometers. It was developed by the Radiometric Calibration and Flight Development Laboratory at Goddard Space Flight Center (GSFC) as a simulator for the GEO-CAPE mission. The first spectrometer in GCAS operates in the ultraviolet to visible (300-490 nm) range for air quality observations of nitrogen dioxide (NO2), ozone (O3), formaldehyde (HCHO), and other trace gases. The second spectrometer operates in the visible to near-infrared (480-900 nm) range to provide measurements of ocean color. GCAS has a typical spatial resolution of 250m across track and 500m along track at an altitude of 9 km, with a frame rate of 12 Hz.

The Langley Aerosol Research Group Experiment (LARGE) is an in situ airborne instrument suite that measures aerosol and cloud microphysical and optical properties, such as size distribution, number concentration, and scattering and absorption coefficients. LARGE includes several instruments, such as the Ultra-High Sensitivity Aerosol Spectrometer (UHSAS), Particle-Into-Liquid Sampler (PILS), Particle Soot Absorption Photometer (PSAP), Cloud and Aerosol Spectrometer (CAS), Cloud Imaging Probe (CIP), and additional cloud and aerosol sensors. The LARGE instruments operate over the 450-700 nm wavelength range, detect particles ranging from 0.003 to 20 μm, and measure at a frequency of 1 Hz. It is primarily used for airborne measurements but can also be deployed on ground-based platforms like vehicles.

The Spectrometers for Sky-Scanning, Sun-Tracking Atmospheric Research (4-STAR) is an airborne sun-sky spectrometer that measures direct solar irradiance and sky radiance. These measurements can be used to retrieve column-integrated information on aerosols, clouds, and trace gases such as aerosol optical depth, extinction, and single scattering albedo. 4-STAR operates in the 350-1650 nm wavelength range and has a typical horizontal resolution of about 100 m.

Generic-Atmospheric State (Gen-AtmsState) refers to non-specific instruments on a platform used for measurements of atmospheric state parameters. These are typically in situ sensors that measure temperature, pressure, humidity, and wind speed/direction. Types of atmospheric state instruments include thermometers, hygrometers, barometers, and anemometers.

Chilled Mirror Hygrometers (CMHs) are in situ sensors that directly measure dew point temperature by collecting water vapor on a chilled mirror surface. The mirror's temperature is lowered with thermoelectric coolers until water vapor from the sample gas condenses as dew or frost. The mirror's temperature is then measured using a platinum resistance thermometer (PRT) to determine the dew point and humidity. CMHs have been utilized on both airborne and ground-based platforms and serve as the NIST traceable reference standard for calibrating other sensors.
