Instrument

HSRL-2
High Spectral Resolution Lidar 2

The Second Generation High Spectral Resolution Lidar (HSRL-2) is an airborne lidar developed by the NASA Langley Research Center. HSRL-2 measures aerosol backscatter at the 355, 532, and 1064 nm wavelengths and aerosol extinction at the 355 and 532 nm wavelengths. It has a horizontal resolution of 1-2 km and a vertical resolution of 15 m, and it takes measurements roughly every 0.5 seconds. It replaced the High Spectral Resolution Lidar (HSRL).

NASA's DC-8 flying laboratory passes Antarctica's tallest peak, Mount Vinson, on Oct. 22, 2012, during a flight over the continent to measure changes in the massive ice sheet and sea ice. Credit: NASA/Michael Studinger (Photography courtesy NASA Images)

Instrument Details

Lidar
Earth Science > Atmosphere > Aerosols > Aerosol Backscatter
Earth Science > Atmosphere > Aerosols > Aerosol Extinction
Earth Science > Atmosphere > Aerosols > Aerosol Particle Properties
Earth Science > Spectral/engineering > Lidar > Lidar Backscatter
Earth Science > Atmosphere > Aerosols > Aerosol Optical Depth/thickness > Angstrom Exponent
Earth Science > Atmosphere > Aerosols > Aerosol Optical Depth/thickness
Earth Science > Spectral/engineering > Lidar > Lidar Depolarization Ratio
Full Column Profile
0.5 s
1-2 km (horizontal), 15 m (vertical)
282 THz, 564 THz, 895 THz
External Linkhttps://doi.org/10.1364/AO.57.006061
  • Chris Hostetler, Richard Ferrare

  • Chris Hostetler

  • NASA Langley Research Center

  • NASA Science Mission Directorate, ESTO, AITT, Radiation Science Program

  • Currently unavailable
