Instrument

HARP
HIAPER Airborne Radiation Package

The HIAPER Airborne Radiation Package (HARP) is an in situ airborne radiometer developed by NCAR, the University of Colorado, the Leibniz-Institute for Tropospheric Research, Metcon, Inc., and enviscope GmbH. The instrument measures actinic flux and spectral irradiance. HARP operates from 280 to 680 nm for actinic flux and from 260 to 2400 nm for irradiance. It typically samples at 1 Hz.

NASA's DC-8 flying laboratory passes Antarctica's tallest peak, Mount Vinson, on Oct. 22, 2012, during a flight over the continent to measure changes in the massive ice sheet and sea ice. Credit: NASA/Michael Studinger (Photography courtesy NASA Images)

Overview

Instrument Details

Measurement Type

Spectrometer/Radiometer

Measurement/Variables

Earth Science > Atmosphere > Atmospheric Radiation > Actinic Flux

Earth Science > Atmosphere > Atmospheric Radiation > Spectral Irradiance

Earth Science > Atmosphere > Atmospheric Radiation

Vertical Measurement Regions

Troposphere

Temporal Resolution

1 Hz

Spatial Resolution

Point

Measurement Frequency

441-1071 THz (actinic flux), 125-1153 THz (spectral irradiance)

Calibration Details

https://doi.org/10.5065/D6FF3QDN

Online Information

Lead Investigator
Samuel R. Hall, Kirk Ullmann
Technical Contact
Samuel R. Hall
Instrument Maker
NCAR, University of Colorado, Leibniz-Institute for Tropospheric Research, Metcon, Enviscope Gmb
Funding Source
NSF
Overview Publications
Currently unavailable
Repository
- Unpublished
