Instrument

HAMSR
High Altitude Monolithic Microwave integrated Circuit (MMIC) Sounding Radiometer

The High Altitude Monolithic Microwave integrated Circuit (MMIC) Sounding Radiometer (HAMSR) is an airborne microwave sounder developed by the Jet Propulsion Laboratory under the NASA Instrument Incubator Program. HAMSR measures brightness temperature which can be used to derive three-dimensional profiles of temperature, water vapor, and cloud liquid water in the atmosphere. It operates across 25 spectral channels in 3 microwave bands (50-60 GHz, 118 GHz, 183 GHz) and has a sampling frequency of 5 seconds. HAMSR has a horizontal spatial resolution of 2 km at nadir and a field of view of about 40 km at an altitude of 20 km.

Image of the HAMSR instrument
NASA's DC-8 flying laboratory passes Antarctica's tallest peak, Mount Vinson, on Oct. 22, 2012, during a flight over the continent to measure changes in the massive ice sheet and sea ice. Credit: NASA/Michael Studinger (Photography courtesy NASA Images)

Instrument Details

Spectrometer/Radiometer
Earth Science > Atmosphere > Atmospheric Temperature
Earth Science > Atmosphere > Clouds > Cloud Microphysics > Cloud Liquid Water/ice
Earth Science > Atmosphere > Atmospheric Water Vapor > Water Vapor Indicators > Humidity > Absolute Humidity
Earth Science > Atmosphere > Atmospheric Water Vapor
Earth Science > Atmosphere > Atmospheric Water Vapor > Water Vapor Indicators > Water Vapor
Earth Science > Atmosphere > Atmospheric Water Vapor > Water Vapor Indicators > Humidity > Relative Humidity
Earth Science > Spectral/engineering > Microwave > Brightness Temperature
Earth Science > Atmosphere > Atmospheric Temperature > Upper Air Temperature
Earth Science > Atmosphere > Atmospheric Water Vapor > Water Vapor Indicators > Total Precipitable Water
Column Integrated
5 s
2 km
50-60 GHz, 118 GHz, 183 GHz
External Linkhttps://doi.org/10.1109/TGRS.2011.2125973

Filter data products from this instrument by specific campaigns, platforms, or formats.

Campaigns
CAMPAIGNS
Platforms
PLATFORMS
Formats
FORMATS
External Link10.5067/HS3/HAMSR/DATA201
External Link10.5067/CPEXAW/HAMSR/DATA101
External Link10.5067/CAMEX-4/HAMSR/DATA101
External Link10.5067/CPEXCV/HAMSR/DATA101
External Link10.5067/EPOCH/HAMSR/DATA101
